Uniview XVR301-08F FHD XVR 8CH 2M

Name: Uniview XVR301-08F FHD XVR 8CH 2M
Brand: Uniview
SKU: XVR301-08F
Availability: InStock

Support H.265/H.264 video formats
• Support audio over coaxial cable (only for TVI cameras)
• Control the dual-light of UNV analog cameras under TVI
• Support analog camera upgrade over coaxial cable
• Support TVI, AHD, CVI, CVBS, IP cameras with adaptive access
• 4/8/16-channel BNC input
• Support 1-ch HDMI output, 1-ch VGA output at up to 1920*1080
• HDMI and VGA simultaneous output
• Long transmission distance over coaxial cable
• Support mainstream cameras of ONVIF and RTSP protocols

رمز المنتج: XVR301-08F

شحن سريع وأمن

بياناتك محمية دائماً

تسوق أمن معنا

بياناتك محمية دائماً

السعر الأصلي هو: EGP1,700.00.السعر الحالي هو: EGP1,350.00.

مقارنة

0 الأشخاص الذين يشاهدون هذا المنتج الآن!

التسليم السريع

سوف يقوم احد مندوبى الشحن بالتسليم إلى العنوان المحدد

الشحن يصلك فى خلال

ايام 2-3

طرق الدفع :- الدفع عند الأستلام - فودافون كاش - فورى - انستاباى

XVR301-08F

Video/Audio Input

IP Video Input

2-ch

Analog Video Input

8-ch, BNC

Max IP Video Input

10-ch

Supported Analog Camera Types

Support AHD input: 1080P@30fps 720P@30fps Support TVI input: 1080P@30fps 720P@30fps Support CVI input: 1080P@30fps 720P@30fps Support CVBS input

Video/Audio Output

HDMI Output

HDMI: 1920 × 1080/60 Hz, 1920 × 1080/50 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz

VGA Output

VGA: 1920 × 1080/60 Hz, 1920 × 1080/50 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz

Live View Display

HDMI/VGA: 1/4/6/8/9

HDMI/VGA: 1/4/6/8/9/16

HDMI/VGA: 1/4/6/8/9/25

Encoding/Decoding

Recording Resolution

1080P Lite/720P/D1

Recording Frame Rate

Main stream: 1080P Lite@25fps Sub stream: D1@25fps Main stream: 720P@30fps Sub stream: D1@30fps

Main stream: 1080P Lite@15fps Sub stream: D1@12fps Main stream: 720P@15fps Sub stream: D1@15fps

Main stream: 1080P Lite@12fps Sub stream: D1@12fps Main stream: 720P@15fps Sub stream: D1@15fps

Audio Sample Rate

8 kHz, 16 bit per channel

Audio Bit Rate

64 Kbps per channel

Decoding Capability

Analog:4 x 1080P Lite@25, 4 x 720P@30 IP: 1 x 6MP@20, 2 x 1080P@30

Analog:8x 1080P Lite @15, 8x 720P @15 IP: 1 x 6MP@20, 2 x 1080P@30

Analog:16x 1080P Lite@12, 16x 720P@15 IP: 1 x 8MP@30, 2 x 4MP@30, 4 x 1080P@30, 8 x 720P@30,16 x D1@30

Two-way Audio

N/A

Analog Snapshot

FTP/Schedule/Event Snapshot

FTP/Event snapshot:4-ch snapshot, up to 704*576 resolution, Schedule snapshot:not supported

FTP/Event snapshot:8-ch snapshot, up to 704*576 resolution, Schedule snapshot:not supported

FTP/Event snapshot:16-ch snapshot, up to 704*576 resolution, Schedule snapshot:not supported

Network

Incoming Bandwidth

24Mbps (Up to 32Mbps after all analog channel conversion)

24Mbps (Up to 40Mbps after all analog channel conversion)

24Mbps (Up to 56Mbps after all analog channel conversion)

Outgoing Bandwidth

48Mbps

64Mbps

Remote Users

128

Protocols

TCP/IP, P2P, UPnP, NTP, DHCP, HTTP, HTTPS, DNS, DDNS, SMTP

Browser(Plugin)

IE10, IE11, Chrome 45+, Edge 79+, Firefox 52+

Smart

Analog Smart by XVR

Ultra Motion Detection (UMD)

VCA Search

Behavior Search

Smart Functions by XVR

4-ch (UMD)

8-ch (UMD)

Alarm

General Alarm

Motion

Alert Alarm

IP Conflict, Network Disconnected, Disk offline, Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording/Snapshot Abnormal

GUI Language

20 languages: English, Vietnamese, Thai, Turkish, Spanish (Latin America), Portuguese (Brazil), Spanish, Portuguese, French, German, Italian, Dutch, Polish, Czech, Hungarian, Slovak, Russian, Hebrew, Arabic, Ukrainian

Hard Disk

SATA

1 SATA interface

Capacity

Up to 6 TB for each HDD

External Interface

Network Interface

1 RJ45 10 M/100 M self-adaptive Ethernet Interface

USB

Rear panel: 2 × USB2.0

Power Supply

DC 12 V/1.5 A
